Stroke: 150mm push and pull

Speed: 250mm/s

Max Load: 100kg pull per actuator

Voltage: 110-220V

4 x Slick Boards / Slick Plates (  Optional )

4 x Slick Tires

1 x Center Pivot point bearing assembly + strafing mechanisam ( with carbon fiber rods/tubs  500mm , outre diameter 25mm / inner diameter 15mm or c45s steel rods  optional )

2 x actuators 150mm With Servo Motors made of 6061-T6 Grade Aluminum motor mount cup and motor shaft Cup Anodised

2 x 80 x 80 aluminium Profiles 61-63-T6 Aluminium Grade Black/Red Anodised

2 x 80st-m02430 Servo Motor

2 x Latest AASD-15A V6.3.1 servo drivers latest

2 x 4 Meter Motor Cable shielded cable

2 x 4 Meter Encoder shielded cable

2 x Power Cables

2 x DB25 1.5 meter Male to Male Customized Shielded Cables

Compatible with all 40 series profiles racing rigs for attachment

Compatible with all control systems , thanos , SFX shield.. etc

SimHub

Sim Rcing Studio

Sim Tools

FlyPT Mover

Cockpit

seat

E STOP SWITCH

Controller

Coming Soon
