4 x  Aluminium Holder Cups

4 x Stainless steel casters

4 x Aluminium casters rolling / support plates

1 x Pivot point bearing assembly

2 x pull bar assembly

4 x Aluminium Holder Cups for actuators set

6 x Actuators 150mm With Servo Motors made of 6061-T6 Grade Aluminum motor mount cup and motor shaft Cup Anodised

6 x 80 x 80 aluminium Profiles 61-63-T6 Aluminium Grade Black/Red Anodised

6 x 80st-m02430 Servo Motor

6 x Latest AASD-15A V6.3.1 servo drivers latest

6 x 4 Meter Motor Cable shielded cable

6 x 4 Meter Encoder shielded cable

6 x Power Cables

6 x DB25 1.5 meter Male to Male Customized Shielded Cables

4 x Attachment plates

4 x linear guide rail

8 x  bearing blocks

8 x  bearing blocks Bracket Attachment

15 pcs cable binder with zip ties

Compatible with all 40 series profiles racing rigs for attachment

Compatible with all control systems , thanos , SFX shield.. etc

SimHub

Sim Rcing Studio

Sim Tools

FlyPT Mover

All options doesnt include profiles brackets bolts and nuts except the vertical profile of the pully assembly and the attachments bolts and nuts

Options without servo motors doesnt include the folloaing .

• 80st-m02430 Servo Motor

• Latest AASD-15A V6.3.1 servo drivers latest

• 4 Meter Motor Cable shielded cable

• 4 Meter Encoder shielded cable

• Power Cables

• DB25 1.5 meter Male to Male Customized Shielded Cables

• 15 pcs cable binder with zip ties

Options without Thanos AMC AASD-15A 7 Actuators Controller doesnt include the controller

** EC ULTIMATE KIT WITH SERVO MOTORS 5DOF

115 KG ± 3 kg

** EC ULTIMATE KIT WITHOUT SERVO MOTORS 5DOF

79 KG ± 3 kg
