SFX-100 3DOF 80ST Servo Motor
SFX 100
AED 5300.00
AVAILABLE 7 TO 10 DAYS TO DISPATCH
Highlights:
-Suitable for on road racing as the 100mm stroke does not gives much high shaft left off margin
- A complete 3DOF turn-key motion system
- Flexible to choose from wide motionsd contrrolers
- HUGE list of supported games
- 4 x actuators to move a 440kg cockpit with driver effortlessly
- 100mm stroke travel plus extra 10mm safety tolerance
-Full Aluminium body from top to bottom with extreme parts quality anodising finish ( WITHOUT SCRACHES :))
- Super low center of gravity, mounting point only 60MM with large rubber feet to avoid inner bolt knocking from ground
- Best in class on EMI suppression efficiency
- Perfect for kart racing simulation or junior size / light weight cockpit
-no shaking shafts neither shaft can rattling and inner cylinder knocking (NOT OUR STANDARD)
- One year standard warranty on Servo Motors.
- Five years warranty for actuator casing top to bottom ( 5years)
SFX-100 Super Fast Actuators X 4 Actuator 80st-m02430 Servo Motor + AASD-15A
750 Watt 220V AC Servos
7.5 nm Torque
150mm Travel
245mm/s velocity
Easily move 440kg+ rigs.
4 actuators With/Without Servo Motors made of 6061-T6 Grade Aluminum motor mount cup and motor shaft Cup Anodised
4x 80 x 80 aluminium Profiles 61-63-T6 Aluminium Grade Black Anodised
4 x 80st-m02430 Servo Motor
4 x Latest AASD-15A V6.3.1 servo drivers
4x 4 Meter Motor Cable shielded cable
4x 4 Meter Encoder shielded cable
8 x Attachment Upper and lower brackets ( Powder Coated)
Compatible with all 40 series profiles racing rigs for attachment
Compatible with all control systems , thanos , SFX shield.. etc
SimHub
Sim Rcing Studio
Sim Tools
FlyPT Mover
Not IncludeServo Motors Controller
Options without Motor does not include motor , drive and any cables
Aluminium Holder Cups pack
E-Stop Switch
Full kit plus servo motors approx : 45kg
